Non-contact rotary torque sensor electric motor torque measurement

Good quality Rotary torque sensor for sales
Good quality Rotary torque sensor for sales
I'm Online Chat Now

Non-contact rotary torque sensor electric motor torque measurement

China Non-contact rotary torque sensor electric motor torque measurement supplier

Large Image :  Non-contact rotary torque sensor electric motor torque measurement

Product Details:

Place of Origin: China
Brand Name: Forsentek
Model Number: FYH

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Packaging Details: 1pc/box
Delivery Time: 5~20 working days
Payment Terms: T/T,Western Union or Paypal
Supply Ability: 800pcs/month
Detailed Product Description
Usage: Motor Torque Measurement Theory: Roraty Torque Transformer
Output: 5kHz~15kHz Torque Measurement Direction: Clockwise&Counterclockwise
Capacity: 1NM~3000NM

Non-contact rotary torque sensor electric motor torque measurement

non-contact rotary torque sensor
Features

  • Alloy steel  construction,shaft to shaft configuration,pedestal mount
  • Contactless rotary torque transformer,high rotating speed up to 36000RPM
  • Torque measurement in both clockwise and counterclockwise direction
  • Speed measurement integrated
  • TTL square wave@5V output
  • -5~5V/0-5V/4-20mA output achievable through signal converter
  • Widely used for motor torque measurement,rotating shaft torque measurement

how to measure torque of a rotating shaft
Specifications

Capacity 1NM 2NM 3NM 5NM 10NM 20NM 30NM 50NM 100NM 150NM 200NM 300NM 500NM 700NM 1000NM 1500NM 2000NM 3000NM
Rated output

TTL square wave@5V
Torque: 5kHz~15kHz
Speed: 60 pulses/Rev.

Excitation ±12V DC(Or 24V DC)
Zero balance 10kHz
Non-linearity ±0.2% R.O.
Hysteresis ±0.2% R.O.
Non-repeatability ±0.1% R.O.
Creep(30min) ±0.1% R.O.
Safe overload 150% F.S.
Ultimate overload 200% F.S.
Compensated temp. -10...+40oC
Operating temp. -20...+60oC
Temperature shift zero ±0.01% R.O./oC
Temperature shift span ±0.01% R.O./oC
Insulation resistance >2000M ohms
Ingress protection IP50
Material of element Alloy steel
Cable Ø6*5000mm


Contactless rotary torque transformer FYH
electric motor torque measurement

Rotary torque transducer FYH is produced based on rotary torque transformer system,torque signal is trasmitted from rotating shaft contactlessly,compared to slip-ring type torque sensor,non-contact torque transducer is much more durable due to there is no brush abrasion issue,Dual-direction torque measurement is available and rotating speed measurment is integrated.Analog output -5~5V/0-5V/4-20mA can be achieved through signal converter.

measuring motor torque

motor torque tester

Dimensions:

measuring electric motor torque
