Product Details:
Payment & Shipping Terms:
|
| Usage: | Measure Torque | Theory: | Strain Gauge Torque Sensor |
|---|---|---|---|
| Output: | Analog Sensor | Type: | Reaction Torque Sensor |
| Capacity: | 20NM 30NM 50NM 100NM 200NM 300NM 500NM |
Features
Dimensions
Specifications
| Capacity | 500NM 300NM 200NM 100NM 500NM 20NM |
| Rated output | 1.0-2.0mV/V |
| Excitation | 5-15V |
| Zero balance | ±2% R.O. |
| Nonlinearity | ±0.15% R.O. |
| Hysteresis | ±0.15% R.O. |
| Nonrepeatability | ±0.05% R.O. |
| Creep(30min) | ±0.1% R.O. |
| Safe overload | 150% F.S. |
| Ultimate overload | 200% F.S. |
| Compensated temperature | -10...+40oC |
| Operating temperature | -20...+60oC |
| Temperature shift zero | ±0.01% R.O./oC |
| Temperature shift span | ±0.01% R.O./oC |
| Input resistance | 350±30 ohms |
| Output resistance | 350±10 ohms |
| Insulation resistance | >5000M ohms |
| Ingress protection | IP60 |
| Material of element | Alloy steel/Stainless steel |
| Cable | Ø5*3000mm |
| Wiring code | Red--E+ Black--E- Green--S+ White--S- |
Square Flange Style Reaction Torque Transducer
